Edge computing modules
Edge AI modules and developer kits for on-board vision, perception and autonomy.
Jetson Orin Nano-class kits are the standard on-board computer for vision and autonomy work: an Arm CPU, an Ampere-generation GPU with tensor cores and enough I/O for cameras, lidar and the vehicle bus.
Supply of these modules follows allocation from the chip vendor, so lead times move; we keep an eye on stock and tell you before you order.
Specifications
Typical range; final values per model and order.
| CPU | 6-core Arm Cortex-A78AE |
|---|---|
| GPU | 1,024-core Ampere with 32 Tensor cores |
| AI performance | Up to 40 TOPS (INT8) |
| Memory | 8 GB LPDDR5, 68 GB/s |
| Interfaces | Gigabit Ethernet, 4× USB 3.2, DisplayPort, 2× M.2, 40-pin header |
| Power | 7 to 15 W |
| Form factor | Developer kit with carrier board; module only on request |
How it ships
What we inspect before it leaves the factory
- Boot test and serial number record on a sample
- Seal and accessory check on each retail box
- Fan and heatsink fit verified
